Environmental
- Temperature: 32° to 104° F (0° to 40° C)
- Humidity: 10% to 80% RH (non-condensing)
- Cooling: 102 cubic feet per minute (CFM) recommended
- BTU: 1950 BTU/hr
Power
- Input Power: 120V AC 5A 60 Hz
- Fuse Rating: 8A/250V Glass Fuse
- Maximum Power: 580 watts
Operating Parameters
- Rated Power: 40 WPC at 8 ohms, 50 WPC at 4 ohms; (0.1% THD+N, 1kHz)
- Input Impedance: 33k ohms
- Input Sensitivity: 750mV for 40W at 8 ohms
- Overall Voltage Gain: 27.5dB
- Frequency Response: Bandwidth limited from 20Hz to 20kHz +0.8dB
- Distortion THD+N: THD+N < 0.07% from 20Hz to 20kHz, All channels driven at 8 ohms (1 Watt)
- Signal-to-Noise Ratio: > 90dB
- Input Triggers: 3 – 24V AC/DC 5mA
- Output Triggers: 12V DC 100mA
Regulatory
- Safety and Emissions: FCC Part 15 | UL-60065
- RoHS Compliant
Minimum Supported Release
- Savant OS da Vinci 6.0.1
