Dimensions
- Length: 5.5 in / 14 cm
- Width: 3.63 in / 9.2 cm
- Height: 1.13 in / 2.7 cm

Power
- 8-18V DC • 0.5A • tip positive
Additional Specifications
- Ethernet/AVB Ports: 5*
- Ethernet ports: 1**
- Operational bandwidth: 10 / 100 / 1 Gigabit
- Front panel: 12 x activity LED
*Note: 5 AVB devices can be connected.  When more than 5 AVB ports are needed, multiple MOTU devices can be interconnected, leaving 4 ports available on the first and last MOTU device, and 3 ports available on all others.  For example, to interconnect 14 AVB devices, you would use 4 MOTU devices (4+3+3+4).
**Note: The five AVB ports can also be used for Ethernet
